Ray‑Ran Floor‑Mounted Falling Dart Impact Tester – Reliable Impact Testing for Films & Flexible Materials

This video introduces the Ray‑Ran Floor‑Mounted Falling Dart Impact Tester, a robust, high‑stability system designed to determine the impact resistance of plastic films, laminates, and flexible packaging materials. Using a controlled free‑fall dart method, the tester delivers accurate, repeatable results for QA labs, R&D teams, and production environments evaluating material toughness and failure behaviour.

Key Features of the Falling Dart Impact Tester

• Floor‑mounted design for maximum stability and repeatability
• Ideal for films, laminates, flexible packaging, and thin‑sheet materials
• Adjustable drop heights and interchangeable darts/weights
• Precision‑guided drop mechanism ensures consistent impact delivery
• Supports ASTM and ISO falling‑dart impact standards
• Suitable for brittle‑fracture, puncture, and failure‑mode analysis
• Designed for high‑throughput QA and production‑testing workflows

What the Video Shows

• 00:00 – Introduction to the Ray‑Ran Falling Dart Impact Tester
• 00:40 – ASTM D4272 – Total Energy Method
• 02:13 – ASTM D1709 – Staircase Method
• 04:03 – Adding / Removing weights

Why Falling‑Dart Impact Testing Matters

Falling‑dart impact testing helps manufacturers understand:

• Material toughness and puncture resistance
• Performance under sudden impact or drop conditions
• Suitability for packaging, food contact, medical films, and industrial applications
• Variability between production batches
• Compliance with ASTM D1709, ISO 7765, and related standards

The Ray‑Ran Floor‑Mounted Falling Dart Impact Tester enables:

• Accurate, repeatable impact‑energy delivery
• Flexible test configurations for different materials and thicknesses
• Reduced operator variability
• Stronger QA documentation and traceability

It’s an essential tool for any organisation evaluating flexible‑material durability.

Technical Summary

• Floor‑mounted, high‑stability design
• Adjustable drop height and interchangeable darts/weights
• Precision‑guided drop mechanism
• Suitable for films, laminates, and flexible packaging materials
• Ideal for QA labs, R&D centres, and production‑testing workflows

For full technical specifications, visit the product page to download the product sheet.

Speak With an Expert

If you’re looking to improve impact‑testing accuracy or evaluate flexible‑material performance more effectively, our team is here to help. Contact our experts today.
